INSTALLATION MANUAL
bloc persist
OFF Lock hold
ON
If engines remain immobile in a completely open or completely closed position for more
than an hour, they are enabled in direction of strike until reaching the end run level, or for
3 seconds. This operation takes place once every hour.
N.B.: This function has the purpose of compensating any oil volume decrease in the hydraulic
motors, due to a temperature drop during prolonged pauses, for instance at night, or to
internal leaks.
IMPORTANT - When no adequate mechanical backstops are installed, do not use this
function.
OFF OFF: Excludes the said function.
hold-to-run
OFF Hold-to-run
ON
Hold-to-run operation: the manoeuvre continues as long as the command key is kept pressed.
It is not possible to use the radio transmitter.
OFF Impulse operation: one impulse opens the gate if closed, and closes it if open.
photc. open
OFF Photocells on opening
ON
In case of obscuring, this excludes photocell operation on opening. During the closing phase, it
immediately reverses the motion.
OFF
In case of obscuring, the photocells are active both on opening and on closing. When a photo-
cell is obscured on closing, it reverses the motion only after the photocell is disengaged.
fast cls
OFF Rapid closing
ON Closes 3s after the photocells are cleared before waiting for the set TCA to elapse.
OFF Command not entered.
test phot
OFF Photocell test
ON Activates photocell check (Fig. H)
OFF Deactivates photocell check
test BAR
OFF Electric edge test
ON Activates electric edge check (Fig. H)
OFF Deactivates electric edge check
MASTER
OFF Master/Slave
ON The control panel is set as Master in a centralised connection.
OFF The control panel is set as Slave in a centralised connection.
fixed code
OFF Fixed code
ON
The receiver is congured for operation in xed-code mode, see paragraph on “Radio
Transmitter Cloning”.
OFF
The receiver is congured for operation in rolling-code mode, see paragraph on “Radio
Transmitter Cloning”.
radio prog
ON
Radio transmitter
programming
ON
This enables transmitter storage via radio:
1 – First press the hidden key and then the normal key (T1, T2, T3 or T4) of a transmitter
already memorised in standard mode by means of the radio menu.
2 – Within 10s press the hidden key and the normal key (T1, T2, T3 or T4) of a transmitter
to be memorised.
The receiver exits the programming mode after 10s, other new transmitters can be entered
before the end of this time.
This mode does not require access to the control panel.
OFF
This disables transmitter storage via radio.
The transmitters can only be memorised using the appropriate Radio menu.
1 mot. on
OFF 1 Active Motor
ON Only motor 2 activated (1 leaf).
OFF Both motors are activated (2 leaves).
sca-2ch
OFF
Gate-open or 2nd radio
channel warning light
ON
The output between terminals 21 and 22 is congured as Gate-open warning light, in this case
the 2nd radio channel controls pedestrian opening.
OFF The output between terminals 21 and 22 is congured as 2nd radio channel.
press. swc
OFF
Closing limit switch
pressure
ON
To be used when a closing backstop is present.
This function activates leaf pressure on the backstop, without this being considered as an
obstacle by the ampere-stop sensor.
Therefore the rod continues its stroke for another 0.5s, after intercepting the closing limit
switch or as far as the backstop. This way, by slightly anticipating closing limit switch acti-
vation, the leaves will come to a perfect halt against the end stop plates (Fig. I Rif. A).
OFF
Movement is exclusively stopped by closing limit switch activation, in this case you must
proceed to a precise setting of closing limit switch activation (Fig. I Rif. B).
traffic
light
preflashing
ON
Trac light
pre-ashing
ON Flashing is switched on when movement starts (duration 3s).
OFF Flashing is switched o when movement starts.
traffic
light red
lamp always
on
ON Steadily lit red light
ON Red lights switched on when gate closed.
OFF Lights switched o if gate closed.
