Motherboard Manual
20
4.3 HYBRID CROSSFIREX REQUIREMENTS
Only Windows Vista supports Hybrid CrossFireX function.
A graphics card with Radeon HD3450/HD3470 GPU.
The graphics card driver should support Hybrid CrossFireX technology.
The power supply unit must provide at least the minimum power required by
the system, or the system will be unstable. A power supply above 450W is
recommended under Hybrid CrossFireX mode.
4.4 HYBRID CROSSFIREX INSTALLATION
Step 1: Insert the Hybrid CrossFireX-Ready graphics card into PEX16_1
(Master), and insert the DCCFX-P2 Paddle Card into PEX16_2 (Slave).
PEX16_1(Master)
Radeon HD3450
Radeon HD3470
PEX16_2(Slave)
DCCFX-P2
Paddle Card
Notice: Make sure both cards are seated into slots completely.
Step 2: Connect a 4-pin ATX power cable to Auxiliary Power Connector
(JATXPWR1), this will ensure the stabilization of your system.
Step 3: In the graphics card configuration program, choose “Hybrid
CrossFireX” function. Installation completes.
NOTE
For more detail information of Hybrid CrossFireX function, please visit following
web-sites:
http://game.amd.com/us-en/crossfirex_hybrid.aspx
http://ati.amd.com/technology/hybridgraphics/index.html
