1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Phenom II processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and PowerNow
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 790GX
AMD SB750
Super I/O
ITE 8718
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
H/W Monitor
Fan Speed Contro ller
ITE's "Smart Guardian" function
Main
Memory
DIMM Slots x 4
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR3
Max Memory Capicity 16GB
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1333 / 1066 / 800
Registered DIMM and ECC DIMM is not supported
Graphics
Radeon HD 3300
Onboard side port memory 128MB DDR2
Max Shared V id eo Memory is 512MB
DX10/UVD/HDCP support
(Hybrid) CrossFireX support (by ATI driver)
IDE
AMD SB750
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II
AMD SB750
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 s pecif icat ion co mp liant.
RAID 0,1,5,1+0 support
LAN
Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC888
7.1channels audio out
Supports HD Audio
IEEE 1394
LSI FW322 1394a
PCI Slot x2 Supports PCI expansion cards
PCI Express Gen2 x16 Slot x2 Supports PCI-E Gen2 x16 expansion cards Slots
PCI Express Gen2 x1 Slot x2 Supports PCI-E Gen2 x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
S/PDIF out Connector x1 Supports digital audio out function
On Board
Connector
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
