Biostar TA870U3+ User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
TA870U3+ TA870B
CPU
Socket AM3
AMD Phenom II/Athlon II/Sempron processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and Cool=n=Quiet
(Maximum Watt: 140W)
Socket AM3
AMD Phenom II/Athlon II/Sempron processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and Cool=n=Quiet
(Maximum Watt: 140W)
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 870
AMD SB850
AMD 870
AMD SB850
Super I/O
ITE 8728
Provides the most commonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Monitor
ITE's "S mart Guardian" funct ion
ITE 8728
Provides the most commonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Monitor
ITE's "S mart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/1GB/2GB/
4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
Registered DIMM and ECC DIMM is not
supported
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/1GB/2GB/
4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
Registered DIMM and ECC DIMM is not
supported
SATA 3
Integrated Serial ATA Controller
Data transfer rates up to 6 Gb/s
SATA Version 3.0 specificat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 6 Gb/s
SATA Version 3.0 specificat ion co mp liant
LAN
Realtek RTL 8111E
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Realtek RTL 8111E
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Sound
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 slot x2 PCI Express Gen2 x16 slot x2
PCI Express Gen2 x 1 slot x2 PCI Express Gen2 x 1 slot x2 Slots
PCI slot x2 PCI slot x2
