Bissell 1623 User Manual

Before you clean
1. Plan activities to give your carpet time to dry.
2. Move furniture to another area if cleaning
an entire room (optional).
3. Vacuum area with a dry vacuum cleaner
before deep cleaning.
4. Plan your cleaning route to leave an exit path. It
is best to begin cleaning in the corner farthest
from your exit.
Fill the 2-in-1 water tank
1. Remove the tank from the base of the machine
by lifting the tank carry handle.
2. Carry like a bucket to the sink. Rotate the handle
forward to unlatch the lid. Remove lid, turn over
and locate built in measuring cup.
3. Fill formula to the indicated fill line on the
built in measuring cup and pour into mouth
of the bladder.
4. Fill the bladder with clean hand hot
tap water.
*Do not boil or microwave water as it can
destroy the bladder.
5. Replace the top of the tank by matching
the lid and tank edges. Handle must be in
the forward position in order to replace lid.
Rotate the handle to the carrying position to
latch the lid.
Note: Remember to secure the lid and test
to make sure it is secure before picking up
the tank.
6. Place tank into machine base, seating firmly
in place. Rotate tank handle back into latched
position.
7
www.bissell.com
2
4'
3'
1
3
4
5
6
7
9
10
11
12
EXIT
START
HERE
Operation
1.
2.
4
3.
6.
5.
ug120-4039_1623E_508.indd 7ug120-4039_1623E_508.indd 7 5/19/08 12:29:43 PM5/19/08 12:29:43 PM

Bissell 1623 Specifications

General

Machine type	Walk-behind
Cleaning type	Dry&wet
Cleaning surfaces	Carpet
Operating current	6.25 A
Maximum area covered	- m²
Vacuum air filtering	-
Maximum area performance	- m²/h
Dirty water tank capacity	2.84 L
Working width (standard brush)	266.7 mm
Power source	AC
Maximum input power	- W
Annual energy consumption	- kWh
Cordless	No
Cord length	7.6 m
Hose length	1.8 m
Dust capacity	- L
Product color	Orange
Dust container type	Dust bag
Liquid tank capacity	2.8 L
Carrying handle(s)	Yes

Weight and Dimensions

Weight	7939.8 g
