Front view
Clean/solution tank
Is located on the right of the unit when you
are facing the unit.
Automatic Smart System™ control paneI
Located in the center of the unit and is where
you will begin selection of the smart cleaning
cycle you would like to use (detailed
instructions on page 9).
Dirty/collection tank
Looking at the front of the unit, the dirty/
collection tank is on the left side.
Vacuum flex hose
Wraps around the center of the unit. This
serves as the travel path for dirty water and
formula that is suctioned up into the dirty/
collection tank.
Spray trigger
When cleaning in the manual mode, press
the spray trigger to release water and
formula onto the area to be cleaned.
Underside view
Handsfree cleaning brushes
Provides cleaning action when using the surface
stain or set-in handsfree cleaning cycles.
Spray tip
Water and solution are dispensed here when
cleaning in the handsfree mode.
Vacuum suction nozzles
Provides suction path when using the
handsfree cleaning cycles.
Back view
Handsfree cleaning brushes
Provides an area to see the handsfree
cleaning action.
Flex hose clip
Is attached to the unit and is a guide for the
vacuum flex hose.
Special features
6
www.bissell.com
