Black & Decker BDCS50 User Manual

6
CHARGING PROCEDURE
THE BATTERIES IN YOUR TOOL ARE
NOT FULLY CHARGED AT THE FACTORY.
BEFORE ATTEMPTING TO CHARGE
THEM, THOROUGHLY READ ALL OF THE
SAFETYINSTRUCTIONS.
1. The charger port (7) is keyed to lock out
other chargers. Align the tab in the charger
plug (9) with the key in the chargingport.
2. Plug the charger plug into the charger port
of the tool as shown in Figure B.
3. Plug the charger (8) into any standard 120
Volt 60 Hz electricaloutlet.
4. Let the tool charge initially for at least 23
hours. After the initial charge, your tool
should be fully charged in 23 hours from
a fully discharged condition. Recharge
discharged batteries as soon as possible
after use or battery life may be greatly
diminished. For longest battery life, do not
discharge batteries fully. It is recommended
that the batteries be recharged after
eachuse.
NOTE: The red LED on the charger
indicates the unit is charging, when the
LED is off the unit is charged. NOTE: If
your tool has been deeply discharged it
may take several minutes for the charger
LED to illuminate after connection to
the tool.
WARNING: Do not use tool while it is
connected to thecharger.
WARNING: Fire Hazard. When
disconnecting the charger from the tool, be
sure to unplug the charger from the outlet
first, then disconnect the chager cord from
thetool.
B
IMPORTANT CHARGING NOTES
1. After normal usage, your tool should be fully
charged in 8 - 10 hours. Your tool was sent
from the factory in an uncharged condition.
Before attempting to use it, it must be
charged for at least 9hours.
2. DO NOT charge the batteries in an air
temperature below 40°F (4,5° C) or above
105°F (40,5 °C). This is important and will
prevent serious damage to the batteries.
Longest life and best performance can be
obtained if batteries are charged when air
temperature is about 75°F (23,8° C).
3. While charging, the charger may hum and
become warm to touch. This is a normal
condition and does not indicate aproblem.
4. If the batteries do not charge properly—(1)
Check current at receptacle by plugging in
a lamp or other appliance. (2) Check to see
if receptacle is connected to a light switch
which turns power off when you turn out
the lights. (3) Move charger and tool to a
surrounding air temperature of 40°F (4,5°
C) to 105°F (40,5° C). (4) If the receptacle
and temperature are OK, and you do not
get proper charging, take or send the tool
and charger to your local
BLACK+DECKER
service center.
5. The tool should be recharged when it fails
to produce sufficient power on jobs which
were easily done previously. DO NOT
CONTINUE using product with its batteries
in a depletedcondition.
SAFETY WARNINGS AND
INSTRUCTIONS: DRILLING
AND FASTENING
• Hold tool firmly to control its twistingaction.
WARNING: Tool may stall (if
overloaded or improperly used) causing
a twist. To reduce the risk of injury
always expect the stall. Grip the tool firmly
to control the twisting action and prevent loss
of control which could cause personal injury. If
a stall does occur, release the trigger
immediately and determine the reason for the
stall before re-starting.
ASSEMBLY AND ADJUSTMENT
ROTO BIT HOLDER (FIGURE C - D)
The tool can store eight 1” (25mm) long
fastening bits in the roto bit holder (3).
CAUTION: Do not attempt to store
longer bits or drill bits in theholder.
• Pull the bits straight out toward the back
of the screwdriver as shown in Figure C.
Snapping them in and out from the top can
damage theholder.
• The tool is also equipped with a rotating
door (10) to coe the bits (Figure D).
C
