Use As A Blower
WARNING: Ensure product is switched off and disconnected from the power supply.
Fit fan cover 14 as shown in Fig. N until audible click is heard.
Attach the blow tube assembly to the power head as shown in Fig. D.
Connect the cord on the power head to the power supply (Fig. M).
Hold the blow tube approximately 7 inches (180 mm) above the ground, turn the blower/vac on and using a
sweeping motion from side to side, advance slowly keeping the accumulated debris/leaves in front of you as
shown in Fig. N.
Once you have blown the debris/leaves into a pile, you can convert to vacuum mode to collect the debris.
Using the air concentrator will help remove matted debris and leaves.
USE AS A VACUUM Vacuum Mode
WARNING: Ensure product is switched off and disconnected from the power supply. To fit the leaf collection bag
assembly to product:
Remove blow tube.
Push the flexible collection tube assembly onto the power head until it is in the fully locked position and an
audible click is heard. (Fig. F).
Remove the fan cover 14 from the bottom of the power head by inserting a screwdriver/hSex key in the slot on
the end of the fan cover (located on the back of the power head), and removing the fan cover. (Fig. I)
Attach the vacuum tube assembly to the power head (Fig. J) by locating the assembly as indicated by arrow,
then pivot about this point until the locking/release catch is fully engaged and an audible click is heard..
Roll the open end of the bag and latch the retaining clip 17 closed. (Fig. Q)
Connect the cord on the power head to the power supply (Fig. M).
Position the tube slightly above the debris/leaves. Turn the blower/vac on, then using a sweeping motion the
debris/leaves will be sucked up the tube, mulched and deposited into the collection bag (Fig. O) .
As the collection bag fills, the suction power will decrease. Turn the blower/vac off and unplug from power supply
before emptying collection bag.
