Page 12
EXHAUST HOSE INSTALLATION
The air exhaust hose and hose inlet must be installed or removed from the portable
air conditioner in accordance with the way it is being used:
COOL, DEHUMIDIFY and HEAT (Heat model BPACT12HWT and BPACT14HWT
only): Air exhaust hose and hose inlet should be connected to the portable
air conditioner.
FAN: Air exhaust hose and hose inlet should be disconnected from the portable air
conditioner.
To install:
1. The hose outlet and inlet are pre-assembled to the air exhaust hose.
2. Align the hose inlet with the slots over the air exhaust hose housing outlet to
assemble.
3. Insert the hose outlet into the window panel.
4. Afx the hose outlet into the window slider kit and seal.
NOTE: The exhaust hose can be compressed or extended
moderately, but it is desirable to keep the length to a
minimum. Also make sure that the hose does not
have any sharp bends.
SET UP & USE
