APPLIANCE POWER CONSUMPTION
MAXX SST™ inverters are ideal for powering:
Lights
TVs and TV/DVD (VCR) combinations units
Radio receivers/transceivers and stereo systems
Computers and peripheral equipment
Refrigerator/freezers
Small microwave ovens
Household appliances
Dry and/or wet/dry vacuums
Heavy duty power tools & chargers
Sump pumps, motors and other electric-powered equipment
Most electrical tools, appliances and audio/video equipment have labels that show the unit’s power
consumption in amps, watts, or both. To avoid inverter shutdown and possible damage to the inverter, avoid
exceeding the wattage rating of this unit. To obtain a rough estimate of the current (in amperes) the power
source must deliver where the power consumption of the tool or device is given in watts AC, simply divide the
power consumption of the load by 10.
Example: If a load is rated at 200 watts AC, the power source must be able to deliver: 200 divided by 10 = 20
amperes.
The inverter has built-in overload protection so that if you do exceed the inverter’s output capacity continuously,
the unit will automatically shut down. Once the excessive load is removed, the inverter can be restarted and
resume normal operation.
Note:
To restart the inverter, turn it off, and then on again. The on/off Switch is located on the unit’s Front Panel
(refer to the “Control and Functions” section of this Instruction Manual).
The inverter powers resistive loads the easiest; however, larger resistive loads, such as electric stoves or
heaters, could draw more wattage than the inverter can deliver on a continuous basis.
CAUTIONS
Ensure that total continuous power consumption of all tools and/or appliances connected to the inverter (and in
use) does not exceed the inverter’s continuous watts rating. Also ensure that start-up wattage for inductive
loads does not exceed peak watts for more than a second.
Appliances such as microwave ovens will normally draw more than their rated current and could possibly
overload the inverter when operating simultaneously with other appliances. For example: A 600 watt
microwave oven draws approximately 940 watts.
The following chart shows the approximate amperage and corresponding wattage at 120 volts AC for various
common tools and appliances.
APPLIANCE CONSUMPTION IN AMPS AND WATTS CHART
APPLIANCE AMPS@ WATTS@
120VAC 120VAC
Laptop Computer 0.45 55
Household Power Mixer 1.83 220
240-Watt Stereo/Amplifier 2.01 242
Refrigerator 2.75 330
3/8" Variable Speed Drill 2.75 330
Variable Speed Jig Saw 2.75 330
SINE WAVE
MODIFIED
SINE WAVE
5
VEC054D_ManualEN_092107.qxp 9/24/2007 3:40 PM Page 5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Black & Decker MAXX SST and is the answer not in the manual?

Black & Decker MAXX SST Specifications

Power IconPower
maximum continuous power2000 watts
surge capacity (peak power)4000 watts
output voltage range105-125 volts
output voltage110/120 VAC
over voltage shutdown15.5 ± 0.5 volts DC
low voltage shutdown10.0 ± 0.3 volts DC
Efficiency IconEfficiency
maximum efficiency> 87%
full load efficiency> 82%
Electrical Characteristics IconElectrical Characteristics
output frequency58-62 Hz
no load current draw> 1.0 amp
thermal shutdown auto resetYes
Connections IconConnections
north american standard outlets3
ANL fuse rating for direct hardwire500
proper cable gauge (AWG) @ 6 ft.1/0
proper cable gauge (AWG) @ 10 ft.3/0
