ENGLISH
10
Bump Feed Trimmer Line Feed
Your trimmer uses .065" (1.65 mm) diameter, round nylon
cutting line. During use, the tips of the nylon lines will
become frayed and worn. Cutting line will wear faster and
require more feeding if the cutting or edging is done along
sidewalks or other abrasive surfaces or heavier weeds are
beingcut.
As you use the trimmer, the cutting line will get shorter due
to wear. Gently bump the trimmer on the ground while
running at normal speed and the line willfeed.
NOTE: Extending cutting line beyond the 12" (305mm)
swath will negatively affect performance, runtime, and the
life of the trimmer due to potential of damaging the motor.
Doing so may also void thewarranty.
Switching Trimmer On and Off (Fig.A)
WARNING: Never attempt to lock the
trigger in the onposition.
1. To turn the appliance on, squeeze the trigger
1
.
2. To turn the appliance off, release thetrigger.
Proper Hand Position (Fig.J)
WARNING: To reduce the risk of serious
personal injury, ALWAYS use proper hand position
asshown.
WARNING: To reduce the risk of serious
personal injury, ALWAYS hold securely in anticipation
of a suddenreaction.
Proper hand position requires one hand on the main
handle
4
and one hand on the auxiliary handle
5
.
WARNING: Always use proper eye
protection that conforms to ANSI Z87.1 (CAN/CSA
Z94.3) while operating thisappliance.
CAUTION: Before you begin trimming, only
use the appropriate type of cutting line.
CAUTION: Inspect area to be trimmed and
remove any wire, cord, or string‑like objects which
could become entangled in the rotating line or spool.
Be particularly careful to avoid any wire which might
be bent outwardly into the path of the appliance, such
as barbs at the base of a chain linkfence.
OPERATION
WARNING: To reduce the risk of serious
personal injury, turn unit off and disconnect
it from power source before making any
adjustments or removing/installing attachments
or accessories, when replacing line, or prior to
cleaning. An accidental start‑up can causeinjury.
Releasing the Cutting Line (Fig.A)
In transit, the cutting line is taped to the spool housing
12
.
Remove the tape holding the cutting line to the spoolhousing.
Attaching Extension Cord (Fig. G)
An extension cord retainer
2
is built into the main handle
that prevents the cord from comingunplugged.
To use this feature, simply double the extension cord
about 8" (203mm) from the end, and insert it into the
slot
17
in the end of the handle area as shown in Fig.G.
Hook the loop formed by doubling the cord over the
extension cord retainer
2
. Gently tug on the cord to
insure that it is firmly retained in the mainhandle.
Plug the receptacle end of the extension cord into the
power cord plug
3
in the mainhandle.
Installing the Edge Guide (Fig.E, F)
1. Locate the edge guide
10
and spread it apart as shown
in Fig B so it will attach to the motor housing
9
.
2. Insert the two edge guide ends
13
into the retaining
holes
14
on the motor housing
9
.
3. DO NOT insert the edge guide ends into the fan
slots as shown in Fig C.
Attaching the Auxiliary Handle (Fig. E)
The auxiliary handle is shipped with the handle screw
15
partially threaded in to prevent loss.
1. Remove the handle screw
15
with a crosshead
screwdriver.
2. Slide the auxiliary handle
5
onto the main housing
6
.
3. Insert the handle screw
15
through the
auxiliaryhandle
5
and the main housing
6
and
securely tighten using a crosshead screwdriver.
Installing the Guard (Fig.E, F)
WARNING: Never remove the guard.
Damage or personal injury couldresult.
WARNING: NEVER OPERATE
APPLIANCE WITHOUT GUARD FIRMLY IN PLACE.
The guard must always be properly attached on the
appliance to protect theuser.
1. Remove the guard screw
16
.
2. Slide the guard onto the motor housing
9
.
3. Align the hole in the guard with the hole in the
motorhousing.
4. Using a crosshead screwdriver, insert the guard screw
16
and tightensecurely.
5. Once the guard is installed, remove the covering from the
line cut‑off blade, located on the edge of theguard.
