BLUM SERVO-DRIVE Instruction Leaflet

1
2
3
2
3
21
24W: 12W:
EN
Blum transformers provide power to the drive unit. Blum transformer function can be checked via the
operating mode display (LED).
Blum transformers
Power connection
Operating mode display
(LED) Serial tag
The following parameters must be observed to ensure the error-free functioning of SERVO-DRIVE:
• Blum distance bumpers must be attached
to the front to ensure the required trigge-
ring signal (2 mm) between the pull-out
unit and the cabinet.
• No items can be clamped between the
pull-out unit and the cabinet back and/or
SERVO-DRIVE.
➢ Improper use may cause SERVO-DRIVE for pull-out systems to wear prematurely!
➢ Do not press or pull with force against the movement direction when opening or closing the
drawer.
NOTE
1
2
3
