Replacing components
214
Please observe the best-by date on the
sealant bottle.<
The M Mobility System consists of
1 Sealant bottle and sticker with speed limit
2 Filling hose from sealant bottle to wheel
Model with pressure gauge on hose*
3 Connector and cable for lighter socket
4 Mounting for sealing bottle
5 Compressor
6 On/Off switch
7 Pressure gauge for indicating tire inflation
pressure
8 Screw on pressure gauge for reducing tire
inflation pressure
9 Connecting hose for connecting compres-
sor and sealant bottle or compressor and
wheel
Connector, cable and connecting hose are
stored in the compressor housing.
Model with pressure gauge integrated
in housing*
3 Connector and cable for lighter socket
4 Mounting for sealing bottle
5 Compressor
6 On/Off switch
7 Pressure gauge for indicating tire inflation
pressure
8 Button for reducing tire inflation pressure
9 Connecting hose for connecting compres-
sor and sealant bottle or compressor and
wheel
Connector, cable and connecting hose are
stored on underside of compressor.
Using M Mobility System
To repair a flat tire with the M Mobility System,
proceed as follows:
> Fill sealant into wheel, refer to page 214.
> Distribute sealant, refer to page 215.
> Produce tire inflation pressure, refer to
page 215.
Filling sealant into wheel
Strictly comply with the specified order,
otherwise highly pressurized sealant
could escape.<
1. Shake sealant bottle.
2. Screw hose 9 onto connection of sealant
bottle.
3. For model with pressure gauge on hose:
Make sure that screw 8 on pressure gauge
is closed.
