EN/12
Retrofit/Installation kit No. 65 90 0 028 873 84 64 25,805 (others see cover sheet)
Installation Instructions no. 01 29 0 029 541 01 29 0 029 544 Issue date: 04.2001
7. To prepare the installation site for the microphone in cars without a sunroof
0
0
0
Take the required template out of the retrofit kit
and cut it out.
Then place the required template against the rear
external contour of the interior light (20) and affix it
to the headlining (21).
Cut out the required opening (22) with a sharp
knife.
As you cut out the material ensure that you
do not damage any cables/leads.
"
Remove the template again.
0
Push the hands-free kit sub-frame (8) through the
opening (20) into the headlining (21).
Insert the hands-free kit frame (7) into the opening
(20) and clip the hands-free kit sub-frame (8) to the
hands-free kit frame (7).
Secure the microphone trim (6) in the hands-free
kit frame (7).
.
20
22
21
E39
F 39 0967 B
8
7
6
21
20
F 39 0968 B
