With Xenon-headlights, the following lights are
designed with LED technology:
▷ Parking lights and roadside parking lights.
▷ Turn signals, incl. side indicators
▷ Daytime running lights
Contact your service center in the event of a
malfunction.
Turning lamp on the Xenon headlight
Follow general instructions, refer to page 193.
The illustration shows the left side of the en‐
gine compartment.
55-watt bulb, H3.
1.
Turn the lid and remove it.
2. Detach the wire bracket.
3. Disconnect the cable at the plug-in con‐
nection and remove the bulb.
4. Insert the new bulb. Ensure that the bulb
has the correct orientation. Because of its
shape, the bulb can only be inserted in one
direction.
5. Secure the bulb with the wire bracket.
6. Connect the bulb.
7. Mount the lid.
LED headlights
Light-emitting diodes (LEDs)
With LED headlights, all front lights and side
indicators are designed with LED technology.
Contact your service center in the event of a
malfunction.
Tail lights, bulb replacement
At a glance
1 Turn signal/brake lamp
2 Reversing lamp
3 Inside brake lamp
4 Rear lamp
5 Outside brake lamp
6 Rear reflector
Turn signal, outer brake, tail, and
license plate lights
Follow general instructions, refer to page 193.
These lights feature LED technology.
Contact your service center in the event of a
malfunction.
Seite 195
Replacing components Mobility
195
Online Edition for Part no. 0140 2 956 361 - X/14
