New Generation N62 Engine Chapter 1 P.7
Course Contents/Background Material
© BMW AG, Service Training
Fig. 5: N62 engine rear view
Index Description
1 Camshaft position sensor, cylinder bank 5-8
2 Valvetronic eccentric shaft position sensor, cylinder bank 5-8
3 Valvetronic eccentric shaft position sensor, cylinder bank 1-4
4 Camshaft position sensor, cylinder bank 1-4
5 Secondary air valves
6 Servomotor for variable intake manifold
KT-7681
