New Generation N62 Engine Chapter 3 P.45
Course Contents/Background Material
© BMW AG, Service Training
The VANOS unit gear teeth have been brought into line with the
new toothed chain.
The VANOS unit for the cylinders 1-4 outlet shaft has a mounting
for the vacuum pump drive.
A spring plate has been fitted between the VANOS unit and the
vacuum pump drive to reduce wear.
