New Generation N62 Engine Chapter 3 P.72
Course Contents/Background Material
© BMW AG, Service Training
The oil sump consists of two parts.
The upper section of the oil sump is made from cast aluminium
and is sealed to the crankcase with a rubber-coated sheet steel
gasket.
The double-skinned lower section of the oil sump is flanged to
the upper section of the oil sump. The upper section of the oil
sump is sealed using a rubber-coated sheet steel gasket.
The upper section of the oil sump has a crossed-shaped cut-out
oil filter element recess.
The upper section of the oil sump is sealed to the oil pump using
a sealing ring.
