BMW R 1150 GS User Manual

111
13
General information and controls
1
R 1150 GS Adventure
Connection
Power socket 1, with a load
rating of max. 60 W (5 A), is
intended only for connecting
extras mounted in the cockpit
or on the handlebars, for
example GPS, Roadbook,
Tripmaster, etc.
Wiring
L Note:
Have the wiring installed by a
specialist workshop, preferably
an authorised BMW motorcycle
dealer.
d Warning:
Do not, under any circum-
stances, connect consumers
that require exposed wiring
toward the rear (heaters for
helmet visors, intercoms, etc.)
to the power socket.
The wiring must be installed
in such a way that the cable(s)
– are neither too slack nor too
tight
– do not impede the rider
– do not restrict or impede
movement of the
handlebars and/or handling
– cannot be trapped
Power socket, 12 V
10geBKg6.book Seite 13 Dienstag, 19. November 2002 1:11 13

BMW R 1150 GS Specifications

General

Displacement	1130 cc
Bore x Stroke	101 mm x 70.5 mm
Torque	98 Nm at 5, 250 rpm
Transmission	5-speed
Final Drive	Shaft drive
Compression Ratio	10.3:1
Wheelbase	1, 507 mm
Engine Type	2-cylinder 4-stroke Boxer
Power	85 hp (62.5 kW) at 6, 750 rpm
Frame	Steel tubular space frame
Front Suspension	Telelever with central spring strut
Rear Suspension	Paralever
Front Brakes	Twin-disc, 305 mm diameter
Rear Brakes	Single 276 mm disc, 2-piston caliper
Seat Height	840 mm (adjustable to 860 mm)
Fuel Capacity	22 liters
