BMW R 1150 GS User Manual

111
7
General information and controls
11
12
13 14 15
16
17
20
19 18
General view, right side
11 Seat lock, helmet holder
12 Toolkit
13 Dual seat
14 Handlebar guard
15 Windscreen, not adjustable
16 Front mudguard extension
17 Knobby tyre, front
OE
18 Primary spark plug, right
19 Secondary spark plug, right
20 Knobby tyre, rear
OE
OE
Optional extra
10ge01g6.fm Seite 7 Montag, 7. Juni 2004 10:13 10

BMW R 1150 GS Specifications

General

Displacement	1130 cc
Bore x Stroke	101 mm x 70.5 mm
Torque	98 Nm at 5, 250 rpm
Transmission	5-speed
Final Drive	Shaft drive
Compression Ratio	10.3:1
Wheelbase	1, 507 mm
Engine Type	2-cylinder 4-stroke Boxer
Power	85 hp (62.5 kW) at 6, 750 rpm
Frame	Steel tubular space frame
Front Suspension	Telelever with central spring strut
Rear Suspension	Paralever
Front Brakes	Twin-disc, 305 mm diameter
Rear Brakes	Single 276 mm disc, 2-piston caliper
Seat Height	840 mm (adjustable to 860 mm)
Fuel Capacity	22 liters
