BMW R 1150 GS User Manual

11
26
General information and controls
Aluminium case
OA
/topcase
OA
• From below, engage hook 4
of the aluminium case in
retaining bar 3
• Lower the aluminium case
onto the plate and check its
alignment
e Attention:
Stops 5 must be in contact with
the plate at front and rear, in-
stead of being seated on it
OA
Optional accessories
• Press lock barrel 1 down as
far as it will go
e Attention:
Make sure that latch 2 is cor-
rectly seated
•Lock the case and remove the
key
Topcase
The procedures for opening and
closing, removing and installing the
topcase are analogous to the pro-
cedures for the aluminium cases.
3
4
5
1
2
1
10geBKg6.book Seite 26 Dienstag, 19. November 2002 1:11 13

BMW R 1150 GS Specifications

General

Displacement	1130 cc
Bore x Stroke	101 mm x 70.5 mm
Torque	98 Nm at 5, 250 rpm
Transmission	5-speed
Final Drive	Shaft drive
Compression Ratio	10.3:1
Wheelbase	1, 507 mm
Engine Type	2-cylinder 4-stroke Boxer
Power	85 hp (62.5 kW) at 6, 750 rpm
Frame	Steel tubular space frame
Front Suspension	Telelever with central spring strut
Rear Suspension	Paralever
Front Brakes	Twin-disc, 305 mm diameter
Rear Brakes	Single 276 mm disc, 2-piston caliper
Seat Height	840 mm (adjustable to 860 mm)
Fuel Capacity	22 liters
