Instrument cluster
There are two versions, depending on
the equipment on your vehicle.
1 Fuel gauge with indicator lamp for
fuel reserve
77
2 Indicator lamp for turn signals 25
3 Speedometer
4 Indicator lamp for high beams 25
5 Tachometer and Energy Control 77
6 Coolant temperature gauge with
"Coolant temperature too high"
indicator
78
7 Indicator and warning lamps
(clockwise) for:
> Parking brake/Brake hydraulic
system, Dynamic Brake Control
(DBC)
22, 24
> Antilock Brake System (ABS) 23
> Brake pads 24
> Airbags 23
> Automatic transmission* 24
> Please fasten safety belts 23
> Cruise control 25
8 Selector lever and program display
for automatic transmission* 68
9 Service Interval Display 78
10 Computer display –
operation via the turn signal lever,
refer to page
82:
> Outside temperature
> Average fuel consumption
> Cruising range
> Average speed
11 Indicator lamp for Dynamic Stability
Control (DSC)
24
12 Indicator lamp for level control
system
* 24
13 Odometer and trip odometer 76
14 Indicator for Check Control 79
15 Reset button for trip odometer 76
16 Indicator and warning lamps
(clockwise) for:
> Fog lamps 25
> Battery charge current 22
> Engine oil level/Engine oil
pressure
22, 24
> Engine Power Control 24
> Service Engine Soon 24
