LTC 2600 Series | Instruction Manual | Multiplexer Set (MS) Commands
Bosch Security Systems | July 12, 2004
EN
|
11
4.2 Detailed Descriptions of MS
Commands
MS-ACTION-ALARM-RELAY <responds to>
<polarity>
NOTE: This command controls Relay 1 only.
This command allows you to set the action/alarm
contacts to close on any action or alarm and change
the multiplexer encoding speed to the action/alarm
recording speed set by the MS-VCR-TI ME-LAPSE
command.
Parameter values for <responds to> and <polarity> are
as follows:
<responds to> 0 Neither (never activates>
1 Relay activates on action
2 Relay activates on alarm
3 Relay activates on action or
alarm
<polarity> 0 Normally open (N/O)
1Normally closed (N/C)
CAUTION: Before making connections to the
action/alarm relay contacts, refer to the LTC 2600
Series Video Multiplexer Instruction Manual for relay
contact ratings.
MS-ACTION-BEEPER <boolean>
This command enables or disables the beeper when an
action condition is present.
Parameter values are: 0 Disabled
1 Enabled
MS-ACTION-CAPTURE <time>
This command allows you to set a specified duration
(from 3 to 60 seconds) for system indications of an
action condition.
Parameter values for <time> are any value from <3>
to <60> seconds.
NOTE: If a value less than <3> is entered (i.e. <0>…<2>),
the value will automatically be set to 3 seconds.
MS-ACTION-CLEAR <camera map>
This command clears the action status of the
multiplexer. For each bit which is 1 <camera map>,
the action status will be cleared.
NOTE: The <camera map> consists of a 16-bit map
with a bit for each camera in the multiplexer. The least
significant bit corresponds to camera 1; the most
significant bit corresponds to camera 16. A set bit
corresponds to an enabled or active camera, depending
on the contact.
MS-ACTION-ENABLE <table 16>
This command enables multiplexer action detectors
corresponding to the values specified in a 16-position
(bit) table. The value in each position of the table
corresponds to the state of a specific action detector (a
value of 1 enables the action detector; a value of 0
disables the action detector).
Parameter values for <table 16> range from <0> to
<65535> (decimal) OR <0> to <FFFF> hex.
EXAMPLE: To enable ONLY Action Detectors 1-4, a
value of 15 decimal (000F hex) is used for <table 16>.
Action Detect. No.:
16 15 14 13 12 11 10 987654321
Position (Bit) #:
15 14 13 12 11 10 9 876543210
1-4 Enabled,
Table Value 15:
(000F hex) 0000000000001111
MS-ACTION-HISTORY <camera map>
This command clears the action status history for
cameras in the camera map.
NOTE: The <camera map> consists of a 16-bit map
with a bit for each camera in the multiplexer. The least
significant bit corresponds to camera 1; the most
significant bit corresponds to camera 16. A set bit
corresponds to an enabled or active camera, depending
on the contact.
