LTC 2600 Series | Instruction Manual | Appendix A
Bosch Security Systems | July 12, 2004
EN
|
43
Function codes may be added together to operate
multiple functions with a single command line. Note
that the current AutoDome series lens only provides
two lens speeds. Speed values 0 to 4 will activate the
slower speed and speed values 5 to 7 will activate the
faster speed. Also note that this command is not
supported on current TC8561 and TC8561A Series
receiver/drivers.
EXAMPLE: If camera number 5 is to be panned left at
maximum speed, enter the following command
(hexadecimal mode shown): LTC 2600>
VARSPEED_PTZ 5 F 0 0 2
APPENDIX A: CCL TECHNICAL
REFERENCE MATERIALS
Basic elements
Extended elements
CCL Grammar Parameter Definitions
digit 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
letter A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S |
T | U | V | W | X | Y | Z
text letter, digit, space, *, +, -, ,, ., /, :, |
i.e. A to Z (uppercase only), 0 to 9, space, * + , - . / : [ ]
boolean: 0 = FALSE, NO, OFF, DISABLED
1 = TRUE, YES, ON, ENABLED
year: 1997..2096
month: 1..12
day: 1..31
hour: 0..23
minute: 0..59
second: 0..59
numeric parameter: [sign] [ 0 <radix prefix> ] <digit> [digit..]
radix prefix: hex prefix
decimal prefix
octal prefix
binary prefix
hex prefix:
x, X
decimal prefix: d, D
octal prefix: o, O
binary prefix: b, B
string parameter: " text "
text
CCL Grammar Parameter Definitions
auxiliary#: 1..7
algorithm: 1..4 (Provisionally, see User Interface for latest list of supported
formats)
1 = LTC 2600 Burle 40 byte format
2 = TC8989B Burle 46 byte format
3 = DMSX8 Dedicated Micros format
4 = LTC8256 Robot format
brightness: 0,,7
0 = Transparent
1 = Black
2-6 = Grey
7 = White
cameo#: 1..16
camera#: 1..16
<camera_list> =
[<camera#]..
camera#
camera# camera_list
camera map: 16-bit map
A camera map consist of a 16-bit map with a bit for each camera
in the multiplexer. The least significant bit corresponds to camera
1; the most significant bit corresponds to camera 16. A set bit
corresponds to an enabled or active camera, depending on the
context.
custom-vcr-model#: 1..6 corresponding to custom VCR setting 1..6
date: year month day if date format is YYYY/MM/DD
month day year if date format is MM/DD/YYYY
day month year if date format is DD/MM/YYYY
<direction> = 1..4 1 = up
2 = right
3 = down
4 = left
<display mode> = 0 = Full Screen
1 = Single Quad
2 = 3 x 3 Multi
3 = 4 + 3 Multi
4 = 12 + 1 Multi
5 = 4 x 4 Multi
6 = 8 + 2 Multi
10 = Dual Quad (Converted to SingleQuad)
11 = Triple Quad (Converted to SingleQuad)
12 = Quad Quad (Converted to SingleQuad)
<dwell time> = 0..60 0 = sequence disabled
1..60 = dwell time in seconds
<high-density> = <boolean>
<i2c device> = 1 decoder 1
2 decoder 2
3 encoder
<language> = 1 = English
2 = German
3 = French
4 = Spanish
5 = Italian
6 = Dutch
<location> 0 = Time\Date display OFF
1 = Time\Date display ON
2 .. 31 (NTSC), 5 .. 33 (PAL) = display row (Turns display ON if
previously OFF)
<logical camera#> = 1..999
<map row#> = 1. .16
<model number> =
<family prefix>
<feature digit>
<digitiser count> /
<pal/ntsc suffix>
<family prefix> = LTC26
<feature digit> = 4 | 6 | 8
4 = 9 channel standard colour
6 = 16 channel standard colour
8 = 16 channel extended colour
<digitiser count> = 1 | 2
1 = simplex model
2 = duplex model
<pal/ntsc suffix> = 50 | 60
50 = PAL model
60 = NTSC model
