Installation Manual Bosch Climate 5000 AA Series Split Type Ductless Air Conditioner / Heat Pump | 7
Bosch Thermotechnology Corp. | 01.2017
Data subject to change
3 Installation Summary - Indoor Unit
Mount Indoor Unit
(Page 16)
STEP
8
Wrap Piping and Cable
(Page 15)
123
Connect Piping
(Page 25)
Connect Wiring
(Page 14)
Prepare Drain Hose
(Page 13)
5 6 7
8
9
Select Installation Location
(Page 9)
Attach Mounting Plate
(Page 9)
Drill Wall Hole
(Page 10)
Determine Wall Hole Position
(Page 9)
1 2
3
4
12cm
(4.75in)
183cm (72in)
12cm
(4.75in)
15cm (5.9in)
Figure 1
