4 Climate 5000 – 6720886922 (2018/04)
Unit Specifications and Features
2 Unit Specifications and Features
2.1 Unit Parts
Front Panel
Remote Control
Display window (A) Display window (B) Display window (C)
Remote Control
Holder (Some Units)
Louver
Power Cable (Some Units)
Display Code
Meanings
defrost
defrost
run
run
timer
timer
“defrost” when DEFROST feature is activated.
“run” when the unit is on.
“timer” when TIMER is set.
“
” Not available for all units.
When ECO function (some units) is activated, the “
” illuminates
gradually one by one as --
-- --set temperature -- ...... in one second
interval.
In other modes, the unit will display your temperature setting.
In FAN mode, the unit will display the room temperature.
When error occurs, it displays error code.
“
” for 3 seconds when:
• TIMER ON is set
• FRESH, SWING, TURBO, or SILENCE features are turned on
“
” for 3 seconds when:
• TIMER OFF is set
• FRESH, SWING, TURBO, or SILENCE features are turned off
“
” when anti-cold air feature is turned on
“
” when defrosting
“
” when unit is self-cleaning
“
” when freeze protection is turned on
“
” when Wireless Control feature is activated (some units)
Fig. 1.
NOTE:
A guide on using the infrared remote is not included in this literature package.
2.2 Achieving Optimal Performance
Optimal performance for the COOL, HEAT, and DRY modes can be
achieved in the following temperature ranges. When your air conditioner
is used outside of these ranges, certain safety protection features will
activate and cause the unit to perform less than optimally.
