Climate 5000 – 6720886922 (2018/04) 5
Unit Specifications and Features
2.3 Inverter Split Type
COOL mode HEAT mode DRY mode
Room
Temperature
17°C - 32°C 0°C - 30°C 10°C - 32°C
Outdoor
Temperature
0°C - 50°C -15°C - 30°C 0°C - 50°C
-15°C - 50°C
(For models
with low
temp. cooling
systems.)
0°C - 60°C
(For special
tropical
models)
0°C - 60°C
(For special
tropical
models)
Table 2.
FOR OUTDOOR UNITS WITH AUXILIARY ELECTRIC HEATER
When outside temperature is below 0°C, we strongly recommend
keeping the unit plugged in at all times to ensure smooth ongoing
performance.
2.4 Fixed-speed Type
COOL mode HEAT mode DRY mode
Room
Temperature
17°-32°C 0°-30°C 10°-32°C
Outdoor
Temperature
18°-43°C -7°-24°C 11°-43°C
-7°-43°C
(For models
with low-temp
cooling
systems)
18°-43°C
18°-54°C
(For special
tropical
models)
18°-54°C
(For special
tropical
models)
Table 3.
To further optimize the performance of your unit, do the following:
• Keep doors and windows closed.
• Limit energy usage by using TIMER ON and TIMER OFF functions.
• Do not block air inlets or outlets.
• Regularly inspect and clean air filters.
For a detailed explanation of each function, refer to the Remote Control
Manual.
2.5 Other Features
• Auto-Restart
If the unit loses power, it will automatically restart with the prior
settings once power has been restored.
• Anti-mildew (some units)
When turning off the unit from COOL, AUTO (COOL), or DRY modes,
the air conditioner will continue to operate at very low power to dry
up condensed water and prevent mildew growth.
• Refrigerant Leakage Detection (some units)
The indoor unit will automatically display “EC” when the unit detects
refrigerant leakage.
• Louver Angle Memory (some units)
When turning on your unit, the louver will automatically resume its
former angle.
For a detailed explanation of your unit’s advanced functionality (such
as TURBO mode and its self-cleaning functions), refer to the Remote
Control Manual.
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual
shape of your indoor unit may differ. The actual shape shall prevail.
Setting vertical angle of air flow
While the unit is on, use the SWING/DIRECT button to set the direction
(vertical angle) of airflow.
1. Press the SWING/DIRECT button once to activate the louver. Each
time you press the button, it will adjust the louver by 6°. Press the
button until the direction you prefer is reached.
2. To make the louver swing up and down continuously, press and hold
the SWING/DIRECT button for 3 seconds. Press it again to stop the
automatic function.
Setting horizontal angle of air flow
The horizontal angle of the airflow must be set manually. Grip the
deflector rod (See Fig. 3) and manually adjust it to your preferred
direction.
For some units, the horizontal angle of the airflow can be set by remote
control. please refer to the Remote Control Manual.
NOTE ON LOUVER ANGLES
When using COOL or DRY mode, do not set louver at too vertical an
angle for long periods of time. This can cause water to condense on the
louver blade, which will drop on your floor or furnishings. (See Fig. 2)
When using COOL or HEAT mode, setting the louver at too vertical an
angle can reduce the performance of the unit due to restricted air flow.
Do not move the louver by hand. This will cause it to become out of sync.
If this occurs, turn off the unit and unplug it for a few seconds, then
restart the unit. This will reset the louver.
CAUTION
Do not keep louver at too vertical an angle for long periods of time. This
can cause water condensation to drip on your furnishings.
