Bosch Climate 5000 Series Service Manual

6
|
Service Manual
Bosch Climate 5000 Series Ductless Air Conditioner / Heat Pump Multi Zone Outdoor Units (01.2023)
2 Part Names and Model Numbers
2.1 Outdoor Models
Voltage Capacity Max Zone Regular Outdoor Units Max Performance Outdoor Units
208-230V
18K 2 BMS500-AAM018-1CSXRC BMS500-AAM018-1CSXHC
27K 3 BMS500-AAM027-1CSXRC BMS500-AAM027-1CSXHC
36K 4 BMS500-AAM036-1CSXRC BMS500-AAM036-1CSXHC
48K 5 BMS500-AAM048-1CSXRC BMS500-AAM048-1CSXHC
Table 1
2.2 Indoor Models
Voltage Capacity Wall Mounted Indoor Units 4-Way Cassette Indoor Units Ducted Indoor Units
115V 12K BMS500-AAS012-0AHWXC
– –
208-230V
6K BMS500-AAU006-1AHWXC
– –
9K BMS500-AAU009-1AHWXC BMS500-AAU009-1AHCXB BMS500-AAU009-1AHDXB
12K BMS500-AAU012-1AHWXC BMS500-AAU012-1AHCXB BMS500-AAU012-1AHDXB
18K BMS500-AAU018-1AHWXC BMS500-AAU018-1AHCXB BMS500-AAU018-1AHDXB
24K BMS500-AAU024-1AHWXC BMS500-AAU024-1AHCXC BMS500-AAU024-1AHDXB
30K BMS500-AAU030-1AHWXC
– –
36K BMS500-AAU036-1AHWXC BMS500-AAU036-1AHCXC BMS500-AAU036-1AHDXB
Table 2
For Indoor Units, please refer to Indoor Unit Service Manual.
2.3 Multizone Congurations
Capacity 2 ZONE 3 ZONE 4 ZONE 5 ZONE
18K
6+6
6+9
6+12
9+9
9+12
12+12
27K
6+12 6+6+6
6+18 6+6+9
9+9 6+6+12
9+12 6+6+18
9+18 6+9+9
12+12 6+9+12
12+18 6+9+18
18+18 6+12+12
6+12+18
9+9+9
9+9+12
9+9+18
9+12+12
12+12+12
Table 3

Bosch Climate 5000 Series Specifications

General

SEER Rating	Up to 22
HSPF Rating	Up to 10
Wi-Fi Connectivity	Yes
Cooling Capacity	9000 - 24000 BTU/h
Energy Efficiency Class (Cooling)	A+++
Energy Efficiency Class (Heating)	A+++
Sound Power Level (Indoor Unit)	19 - 45 dB
Sound Power Level (Outdoor Unit)	Varies by model, typically 50-60 dB(A)
Features	Sleep mode, Timer, Self-Cleaning Function
Energy Efficiency Ratio (EER)	Varies by model
Coefficient of Performance (COP)	Varies by model
Operating Temperature Range (Heating)	-15°C - 24°C
Indoor Unit Dimensions (HxWxD)	Varies by model
Outdoor Unit Dimensions (HxWxD)	Varies by model
Indoor Unit Weight	Varies by model
Outdoor Unit Weight	Varies by model
