User Manual
Bosch Climate 5000 Series Remote Control (06.2022)
5 3 x 3 Cassette Unit Remote Controller
5.1 Operation of Buttons
Figure 38
Van e
Vane
Button Description Function
Power Button Press this button to turn the air conditioner ON or OFF.
MODE Button:
Press this button to select the air conditioner / heat pump's mode of operation.
AUTO --> COOL --> DRY --> HEAT --> FAN
ECO/GEAR Button
Press this button to enter the energy effi cient mode in the following sequence:
ECO --> GEAR(75%) --> GEAR(50%) --> Previous setting mode --> ECO
— While in COOL mode, press this button and the system will automatically be set to 24 °C/75 °F on
Auto fan speed to save energy (only when the set temperature is less than 24 °C/75 °F).
— If the set temperature is above 24 °C/75 °F, the fan speed will change to Auto, the set temperature
will remain unchanged
— Pressing the ECO button, changing the mode or adjusting the set temperature to less than
24 °C/75 °F will stop ECO operation.
Temperature Control
UP Button(
): Push this button to increase the indoor temperature setting in 1°F increments , limited to 86°F.
DOWN Button(
): Push this button to decrease the indoor temperature setting in 1°F increments, limited to 60°F.
Press and hold the UP ( ) and DOWN ( ) buttons together for 3 seconds to alternate the temperature display
between the °C & °F scales.
NOTE: Temperature contol is not available in Fan mode.
SET Button
Press this button to scroll through functions as follows:
Active Clean --> Fresh --> Sleep --> Follow Me --> AP Mode...
The selected symbol will fl ash on the screen. Press the OK button to Confi rm
For more information on the Set function, refer to section 5.4
NOTE: Fresh and AP mode are not available for this unit.
OK Button Press this button to confi rm selection functions.
Table 8
