Technical Data

Digital Laser Rangefinder DLE 70

Professional

Article number

3 601 K16 60.

Measuring range

0.05–70 m

Measuring accuracy (typically) ± 1.5 mm

Lowest indication unit 1mm

Operating temperature

–10 °C...+50 °C

Storage temperature –20 °C...+70 °C

Relative air humidity, max.

90 %

Laser class

Laser type

635 nm, <1 mW

Laser beam diameter (at 25 °C) approx.

– at 10 m distance

– at 70 m distance

6mm

42 mm

Batteries

Rechargeable batteries

4x1.5VLR03(AAA)

4x1.2VKR03(AAA)

Battery live, approximately

– Individual measurements

– Continuous measurement

30000

Automatic switch-off after approx.

–Laser

– Measuring tool (without measurement)

20 s

5min

Weight according to EPTA-Procedure 01/2003

0.18 kg

Dimensions

59 x 100 x 32 mm

Degree of protection (excluding battery compartment)

IP 54 (dust and splash water protected)

A) The working range increases depending on how well the laser light is reflected from the surface of the target (scat-

tered, not reflective) and with increased brightness of the laser point to the ambient light intensity (interior spaces,

twilight). In unfavourable conditions (e.g. when measuring outdoors at intense sunlight), it may be necessary to use

the target plate.

B) In unfavourable conditions (e.g. when measuring outdoors at intense sunlight or an insufficiently reflecting sur-

face), the maximum deviation is

±10 mm per 70 m. In favourable conditions, a deviation influence of ± 0.05 mm/m

must be taken into account.

C) In the continuous measurement function, the maximum operating temperature is +40 °C.

D) Fewer measurements are possible when using 1.2 V rechargeable batteries as compared with 1.5 V batteries.

Please observe the article number on the type plate of your measuring tool. The trade names of the individual meas-

uring tools may vary.

The measuring tool can be clearly identified with the serial number 20 on the type plate.
