Bosch GlassVAC User Manual

4 | English
F 016 L81 779 | (13.12.17) Bosch Power Tools
Product Features (see figures A
and C)
The numbering of the components shown refers to the repre-
sentation of the machine on the graphic pages.
1 Replaceable wiper blade 266 mm
2 Cleaning head 266 mm
3 Cleaning head release button
4 Battery charger level indicator
5 On/Off switch
6 Cover, micro USB port
7 Dirty water tank
8 Drain plug to empty dirty water tank
9 Spray applicator bottle
10 Trigger
11 Spray nozzle
12 Spray applicator head 110 mm
13 Spray applicator head 276 mm
14 Microfiber cloth 110 mm
15 Microfiber cloth 276 mm
16 Wrist strap interface
17 Micro USB cable
18 Charger**
19 Wrist strap
20 Micro USB port
21 Replaceable wiper blade 133 mm
22 Cleaning head 133 mm
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
** country specific
Technical Data
Mounting and Operation
Cordless Window Vacuum GlassVAC
Article number
3 600 HB7 0..
Rated voltage
V= 3.6
Rated capacity
W 15
Protection class
IPX4
Weight according to EPTA-
Procedure 01:2014
kg 0.7
Permitted ambient
temperature
–during charging and
operation*
–during storage
°C
°C
-5... +62
+3...+43
** country specific
Battery Li-Ion
Rated voltage
V= 3.6
Capacity
Ah 2.0
Number of battery cells
1
Battery Charger
Article number
2 60 ...
EU
UK
AU/NZ
KO
... 120 713
... 120 718
... 120 717
... 120 716
Charging current
A1.0
Charging period (battery
discharged)
min 180
Weight according to EPTA-
Procedure 01:2014
kg 0.30 **
Protection class
/ II
Action Figure Page
Product features
A 7
Delivery scope
B 8
Charging the battery pack
C 9
Connect/disconnect the cleaning head
D 9
Filling the spray applicator
Connecting the spray applicator head
E 10
Attaching the microfiber cloth 110 mm
F 10
Connect the applicator head 276 mm
Attaching the microfiber cloth 276 mm
Disconnect spray applicator head
G 11
Using
H–I 12–14
Empty the dirty water tank
I 14
Cleaning the machine
J–K 14–15
Detach the microfiber cloth 110 mm
Cleaning microfiber cloth
L 16
Accessories
M 16
Cordless Window Vacuum GlassVAC
** country specific
OBJ_BUCH-3480-001.book Page 4 Wednesday, December 13, 2017 9:57 AM
9

Bosch GlassVAC Specifications

General

Cordless	Yes
Product color	Black, Red, Silver
Operating time	30 min
Battery voltage	3.6 V
Battery capacity	2000 mAh
Battery recharge time	2.17 h
Number of nozzles	2
Water tank capacity	0.1 L
Maximum working width	- mm
Area cleaned per battery charge	35 m²

Weight and Dimensions

Height	222 mm
Weight	700 g
