English | 5
Bosch Power Tools F 016 L81 779 | (31.1.18)
Initial Operation
Observe the mains voltage! The voltage of the power
source must correspond with the data on the type plate of
the battery charger.
Note: The battery supplied is partially charged. To ensure full
capacity of the battery, completely charge the battery using
the charger before using your machine for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The battery is protected against deep discharging.
When the battery is discharged, the machine will stop.
Battery Charging (see figures A and C)
Note: The micro-USB port 20 for connection of the micro-
USB cable 17 is in the handle.
When the battery charge is low, the charger level indicator 4
flashes green.
When the charger level indicator 4 flashes red the battery
must be charged. Turn machine off and charge the battery.
Connect the machine to the charger 18 using the micro USB
cable 17 provided. Plug the charger 18 into the socket. The
charging process begins.
During the charging procedure, the handle of the machine
warms up. This is normal.
The charger level indicator 4 continuously lights up red during
the charging procedure. When the battery is fully charged, the
charger level indicator 4 continuously lights up green.
Disconnect the charger from the mains supply when charging
process ends.
Observe the notes for disposal.
Troubleshooting
Maintenance and Cleaning
(see figure J – K)
Always clean the product thoroughly after use.
Remove the cleaning head from the main body and rinse.
Whilst cleaning head 2 is removed from the machine, fill the
dirty water tank 7 via the cleaning head aperture to the max
line with clean, warm water. DO NOT fill the dirty water tank 7
via the drain hole. Shake the machine and pour the water out
via the drain plug 8.
Maintenance of the cleaning head
Protect the cleaning heads against damage during storage.
Prevent the wiper blade from touching paper or cardboard, as
this could damage the wiper blades polymer coating.
Spots or lines may be visible on the polymer coating. This is
normal and does not affect the cleaning performance.
After-sales Service and Application
Service
www.bosch-pt.com
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the garden product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com
Problem Possible Cause Corrective Action
Machine will not switch on Battery discharged Recharge battery
Battery too hot/cold Allow to cool/warm
Restricted or no vacuum Cleaning head blocked Unblock cleaning head
Drain plug remove Replace drain plug
Machine turns itself off Battery too hot/cold Allow to cool/warm
Cleaning head blocked Unblock cleaning head
Water leaks from machine Spray applicator not mounted correctly Mount the spray applicator correctly
Battery will not charge Charger not connected correctly Check charger and USB cable connections
Battery too hot/cold Allow to cool/warm
Streaking on windows Wiper blade damaged Replace wiper blade (accessory)
Too much force applied Apply reduced force
Too little force applied Apply more force
OBJ_DOKU-65434-001.fm Page 5 Wednesday, January 31, 2018 3:43 PM
