Bosch GLM 15 User Manual

-9-
Alerts user to
warning messages
Warning Symbol Read Manual Symbol
Alerts user to read manual
Symbols
Features
1 On/Off (Hold button)
2 Display
3 Battery lid
4 Latch of battery lid
5 Serial number
6 Laser warning label
7 Reception lens
8 Laser beam outlet
Display Elements
a Battery low indicator
b Temperature warning
c Laser switched on
d Measurement hold
e Previous measuring value
f Unit of measure
g Current measuring value
Digital Laser Measure GLM 15
Article Number 3601K72810
Measuring range (typical) 6 in - 50 ft (0.15 –15 m
A
)
Measuring accuracy (typical) ±1/8 in (±3.0 mm
B
)
Lowest indication unit 1/16 in (1 mm)
Measuring duration
– typical 0.5 s
– maximal 4 s
Operating temperature +14° F to 104° F (-10° C to +40° C)
Storage temperature -4° F to 158° F (-20° C to +70° C)
Relative air humidity, max. 90 %
Technical Data
The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
The measuring tool is intended for measuring distances, lengths,
heights and clearances. The measuring tool is suitable for
measuring only indoors.
Intended Use
