-10-
Technical Data
Laser Measure GLM 42
Measuring range (typical): 6 in – 135 ft
(0.15 – 40 m)
A
Measuring accuracy (typical)
±1/16 in (±1.5 mm)
B
Lowest indication unit 1/32 in (0.5 mm)
Indirect Distance Measurement and Vial
Measuring range 0°–360° (4 x 90°)
C
General
Operating temperature +14 °F to 113 °F
(-10 °C to 45 °C)
D
Storage temperature -4 °F to 158 °F
(-20 °C to 70 °C)
Relative air humidity, max. 90 %
Laser class
2
Laser type 635 nm, <1 mW
Laser beam diameter at 77 °F
(25 °C) approx.
– at 33 ft (10 m) distance
– at 135 ft (40 m) distance
4/11 in (9 mm)
1-2/5 in (36 mm)
Weight 0.22 lb (0.1 kg)
Dimensions 4.2 x 1.8 x 0.9 in
(106 x 45 x 24 mm)
Automatic switch-off after approx.
– Laser
– Laser measure (without mea-
surement)
20 s
E
5 min
