English - 1
1 Auxiliary handle
2 Clamping lever
3 Belt speed thumbwheel
(PBS 60 E/PBS 75 AE)
4 On/Off switch
5 Lock-on button for On/Off switch
6 Dust box (micro filtersystem)
7 Extraction adapter
8 Outlet piece
9 Latching lever
10 Filter element (micro filtersystem)
11 Adjustment knob for belt position
12 Thread
13 Protective cap
14 Dust passage
Not all of the accessories illustrated or described are
included as standard delivery.
Working safely with this ma-
chine is possible only when the
operating and safety information
are read completely and the in-
structions contained therein are
strictly followed. In addition, the
general safety notes in the enclosed booklet
must be observed. Before using for the first
time, ask for a practical demonstration.
■ Wear protective goggles, ear protection and a
dust protection mask.
■ Wear protective gloves.
■ For long hair, wear hair protection. Work only
with closely fitting clothes.
■ If the mains cable is damaged or cut through
while working, do not touch the cable but im-
mediately pull the mains plug. Never use the
machine with a damaged cable.
■ Connect machines that are used in the open
via a residual current device (RCD) with an ac-
tuating current of 30 mA maximum. Do not op-
erate the machine in rain or moisture.
■ Always direct the cable to the rear away from
the machine.
■ Apply the machine to the workpiece only when
switched on. Switch off the machine only after
it has been lifted from the workpiece.
■ Always switch the machine off and wait until it
has come to a standstill before placing it down.
■ When working with the machine, always hold it
firmly with both hands and provide for a secure
stance.
■ Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
secure than by hand.
■ The machine can be used only for dry sanding.
■ Do not work with materials containing asbes-
tos.
■ Do not continue to use worn, torn or clogged
sanding belts.
■ Care should be taken to ensure that the oper-
ator or foreign objects do not come into contact
with the running sanding belt.
Tool Specifications
Belt sander PBS 60 PBS 60 E PBS 75 A PBS 75 AE
Order number 0 603 275 1.. 0 603 275 6.. 0 603 270 2.. 0 603 270 5..
Rated power [W] 550 550 710 710
Output power [W] 300 300 350 350
No-load belt speed [m/min] 280 230–280 300 200–300
Length of sander belt [mm] 400 400 533 533
Width of sander belt [mm] 60 60 75 75
Belt speed preselection – ● – ●
Connection for self/external dust
collection
● ● ● ●
Weight (without accessories),
approx.
[kg] 2.1 2.1 3.2 3.2
Protection class / II / II / II / II
Please observe the order number of your machine. The trade names of the individual machines may vary.
Machine Elements
For Your Safety
8 • 2 609 932 116 • TMS • 28.02.03
