Bosch PKE611B17E User Manual

en Disposal
12
Fault Cause and troubleshooting
Several hotplates have been used over a prolonged period at high power set-
tings. The hotplate has been switched off to protect the electronics.
1.
Wait a while.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
Despite being switched off by , the electronics have become hot again. All
hotplates have therefore been switched off.
1.
Wait a while.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
and the heat setting flash al-
ternately. A signal sounds.
Hot pan near the control elements. There is a risk of the electronics overheating.
▶
Remove the pan.
a The display goes out shortly afterwards.
and audible signal Hot pan near the control elements. The hotplate has been switched off to pro-
tect the electronics.
1.
Remove the pan.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
The hotplate was on for too long and has switched off automatically.
You can switch the hotplate back on again immediately.
and hotplates do not heat up Demo mode is activated.
1.
Disconnect the appliance from the power supply for 30seconds by briefly
switching off the circuit breaker in the fuse box.
2.
Touch any control within the next 3minutes.
A message with "E" appears on
the display, e.g. E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
a If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the
exact error message when calling.
→"Customer Service", Page13
11 Disposal
Find out here how to dispose of old appliances cor-
rectly.
11.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
This appliance is labelled in accord-
ance with European Directive
2012/19/EU concerning used elec-
trical and electronic appliances
(waste electrical and electronic equip-
ment - WEEE).
The guideline determines the frame-
work for the return and recycling of
used appliances as applicable
throughout the EU.

Bosch PKE611B17E Specifications

General

Hob type	Ceramic
Frame type	Frameless
Product color	Black
Appliance placement	Built-in
Cooking zone 1 type	Regular
Cooking zone 2 type	Simmer
Cooking zone 4 type	Large
Cooking zone 1 power	2000 W
Cooking zone 1 shape	Round
Cooking zone 3 power	1200 W
Cooking zone 4 power	2200 W
Cooking zone 1 diameter	180 mm
Cooking zone 1 position	Left rear
Cooking zone 2 diameter	145 mm
Cooking zone 2 position	Left front
Cooking zone 3 position	Right rear
Cooking zone 4 diameter	210 mm
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Cooking zone 1 power source	Electric
Control type	Touch
Built-in display	Yes
Control position	Top front
Certification	CE, VDE
Number of power levels	17
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Package weight	8000 g

Weight and Dimensions

Depth	522 mm
Width	592 mm
Height	45 mm
Weight	7000 g
Cord length	1 m
Installation compartment width	560 mm
Installation compartment height	39 mm
Installation compartment depth (max)	500 mm
Installation compartment depth (min)	490 mm
