Bosch PLR 25 User Manual

16 | English
2 609 140 620 | (14.7.11) Bosch Power Tools
5 Area measurement button
6 Length measurement button
7 Display
8 Alignment aid
9 Measuring button
10 Volume measurement button
11 Memory retrieve button “M=”
12 Tracking (continuous measurement) button
13 Laser warning label
14 Latch of battery lid
15 Battery lid
16 Laser beam outlet
17 Reception lens
18 Serial number
19 Laser viewing glasses*
20 Laser target plate*
21 Protective pouch
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a Measuring functions
Length measurement
Tracking (continuous measurement)
Area measurement
Volume measurement
b Battery low indicator
c Temperature warning
d Measured value/result
e Unit of measure
f Measurement reference level
g Laser switched on
h Individual measured value (for length measurement: result)
i Measured values stored
Technical Data
Digital Laser Rangefinder PLR 25
Article number
3 603 K16 200
Measuring range
0.05–25m
A)
Measuring accuracy (typically) ± 2.0 mm
B)
Lowest indication unit 1mm
Operating temperature
– 10 °C ... +50 °C
C)
Storage temperature – 20 °C ... +70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
Laser beam diameter (at 25 °C) and at 10 m dis-
tance, approx. 6mm
Batteries
Rechargeable batteries
4 x 1.5 V LR03 (AAA)
4 x 1.2 V KR03 (AAA)
Battery live, approximately
– Individual measurements
– Continuous measurement
30000
D)
5h
D)
OBJ_DOKU-27422-001.fm Page 16 Thursday, July 14, 2011 11:09 AM

Bosch PLR 25 Specifications

General

Maximum operating distance	25 m
Batteries included	Yes
Voltage	1.5 V
Product color	Black, Green
