Bosch PLR 30 User Manual

Nederlands | 671 609 929 J82 • 6.6.07
Functiebeschrijving
Vouw de uitvouwbare pagina met de afbeelding van het meetgereedschap
open en laat deze pagina opengevouwen terwijl u de gebruiksaanwijzing
leest.
Gebruik volgens bestemming
Het meetgereedschap is bestemd voor het meten van afstanden, lengten,
hoogten en tussenruimten en voor het berekenen van oppervlakten en
inhouden. Het meetgereedschap is geschikt voor maatvoering bij bouw-
werkzaamheden, zowel binnen als buiten.
Afgebeelde componenten
De componenten zijn genummerd zoals op de afbeelding van het meetge-
reedschap op de pagina met afbeeldingen.
1 Toets Verwijderen „C”
2 Toets Geheugen aftrekken „M–”
3 Toets Geheugen optellen „M+”
4 Toets voor lengtemeting
5 Toets voor oppervlaktemeting
6 Display
7 Uitlijnhulp
8 Toets Meten
9 Toets voor volumemeting
10 Toets Geheugenwaarde oproepen „M=”
11 Toets voor duurmeting
12 Aan/uit-toets
13 Laser-waarschuwingsplaatje
14 Vergrendeling van het batterijvakdeksel
15 Deksel van batterijvak
16 Uitgang laserstraal
17 Ontvangstlens
18 Serienummer
19 Laserbril*
20 Laserdoelpaneel*
21 Opbergetui
Indicatie-elementen
a Batterij-indicatie
b Temperatuurindicatie
c Meetwaarde/resultaat
d Maateenheid
e Referentievlak van de meting
f Laser ingeschakeld
g Afzonderlijke meetwaarde (bij lengtemeting: resultaat)
h Meetfuncties
Lengtemeting
Duurmeting
Oppervlaktemeting
Volumemeting
i Meetwaarden opslaan
* Niet elk afgebeeld en beschreven toebehoren wordt standaard meegele-
verd.
OBJ_BUCH-145-003.book Page 67 Wednesday, June 6, 2007 9:02 AM

Bosch PLR 30 Specifications

General

Measuring range	0.05 – 30.00 m
Measuring accuracy, typical	± 2.0 mm
Laser diode	635 nm, < 1 mW
Laser class	2
Measuring time, typical	0.5 s
Measuring time, max.	4 s
Power supply	2 x 1.5 V LR03 (AAA)
Automatic deactivation	5 min
Dimensions	100 x 36 x 23 mm
Protection Class	IP54
Battery Life	5000 measurements
