Bosch RH328VCQ User Manual

-7-
<5*;065(3,:*907;065(5+ 7,*0-0*(;065:
0:*655,*; ;/, 73<. -964 ;/, 76>,9 :6<9*, ),-69, 4(205. (5@
(::,4)3@(+1<:;4,5;:69*/(5.05.(**,::690,: Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Model number RH328VC & RH328VCQ
Shank style SDS-plus
B
Maximum Capacities:
Carbide tipped bits 1-1/8"
Thin wall core bits 3-1/4"
6;(9@(44,9
! For tool specifications refer to the nameplate on your tool.
DEPTH GAUGE RELEASE BUTTON
LOCKING
RING
LOCKING SLEEVE
SDS-plus
B
CHUCK
AUXILIARY
HANDLE
HAND GRIP
VIBRATION DAMPER
HANDLE / HAMMER MECHANISM
VARIABLE
SPEED
TRIGGER
SWITCH
FORWARD /REVERSE
SWITCH
DRILL/HAMMER
DRILL
SELECTION DIAL
FIG. 1
DEPTH GAUGE
DUST
SHIELD
3-JAW CHUCK
(Not included, available
as accessory)
VENTILATION
OPENINGS
RELEASE BUTTON SELECTION DIAL
SDS-plus
®
QUICK CHANGE CHUCK
(Model RH328VCQ only)
