Bosch SDL 43 Series User Manual

1 691 626 210 2010-09-20| Robert Bosch GmbH
Technical data | SDL 43x | 15SDL 43x | 15 | 15
en
7. Technical data
7.1 Ambient conditions
Ambient conditions:
Designation Value
Operating temperature -10…+50 °C
Storage temperature -10…+50 °C
Relative humidity
(no condensation)
< 85 %
7.2 SDL 430
Measurement system:
Designation Value
Measurement system Bending bar with strain
gauge
Basic data:
Designation Value
Dimensions (L x W x H) 440 x 2360 x 280 mm
Shaker plate dimensions (L x W) 690 x 273 mm
Maximum test width 2200 mm
Minimum test width 820 mm
Weight approx. 260 kg
Permissible test load per axle 2000 kg
Max. permissible driveover load per
axle
4000 kg
Workplace emission sound pressure
level as per EN ISO 11204
≤ 70 dB(A)
Degree of protection (as per
DIN 40 050)
IP 54
Operating data:
Designation Value
Power supply 3 x 230 VAC / 11,4A / 50-60Hz
3 x 400 VAC / 6,6A / 50-60Hz
Fuse protection (customer) 3 x 20 A / C 3-pole (230 V)
3 x 20 A / C 3-pole (400 V)
Supply cable (customer) 4 x 2,5 mm (230V)
5 x 2,5 mm (400 V)
Rated power of drive motors 2 x 2,5 kW
Motor speed 1360 1/min
cos f of motors 0,75
Max. test frequency 25 Hz
Stroke 6 mm
7.3 SDL 435
Measurement system:
Designation Value
Measurement system Bending bar with strain
gauge
Basic data:
Designation Value
Dimensions (L x W x H) 440 x 2360 x 280 mm
Shaker plate dimensions (L x W) 690 x 273 mm
Weight approx. 270 kg
Maximum test width 2200 mm
Minimum test width 820 mm
Permissible test load per axle 1650 kg
Max. permissible driveover load per
axle
4000 kg
Workplace emission sound pressure
level as per EN ISO 11204
≤70 dB(A)
Degree of protection (as per
DIN 40 050)
IP 54
Operating data:
Designation Value
Power supply
(via master switch box)
3 x 230 VAC / 14,2A / 50-60Hz
3 x 400 VAC / 8,2A / 50-60Hz
Fuse protection (customer) 3 x 20 A / C 3-pole (230 V)
3 x 20 A / C 3-pole (400 V)
Supply cable (customer) 4 x 2,5 mm (230V)
5 x 2,5 mm (400 V)
Rated power of drive motors 2 x 3,0 kW
Motor speed 1420 1/min
cos f of motors 0,7
Test frequency of suspension
tester
0…30 Hz
Noise simulator test
frequency
10…30 Hz
Cut-out limit of
overtemperature safeguard
90 °C
