64 | Water Side Pressure Drop Table
WATER SIDE PRESSURE DROP TABLE
Water Side Pressure Drop Table
Model GPM
Heat Pump water pressure drop Additional pressure drop in hose kit*
Water PD @ 77°EWT with Water in Psi Water PD in Psi
SM024
3 0.7 0.04
4 1.2 0.04
5 1.7 0.09
6 2.4 0.09
7 3.2 0.13
8 4.0 0.17
SM036
4.5 1.3 0.09
6 2.2 0.09
7.5 3.2 0.17
9 4.5 0.22
10.5 5.9 0.30
12 7.5 0.35
SM048
6 1.1 0.09
8 1.8 0.17
10 2.7 0.26
12 3.7 0.35
14 4.9 0.48
16 6.2 0.61
SM060
7.5 1.1 0.17
10 1.9 0.26
12.5 2.8 0.39
15 3.9 0.52
17.5 5.2 0.69
20 6.6 0.91
SM070
9 0.9 0.22
12 1.4 0.35
15 2.1 0.52
18 3.0 0.74
21 3.9 0.95
24 5.0 1.21
* Hose kit pressure drop based on straight hose. Pressure drop may vary depending on installation of hose kits.
