CC408 |
Operators Guide | 23.
Basic Pager Reporting
EN
| 19
Bosch Security Systems | 5/04 | 920050O.OG.112
Figure 7:
Basic Pager Display
6
7
8
0
1
200000
9000
12345
6
8
7
1
2
3
4
5
6
7
8
1 –
Subscriber ID number
2 –
Zone status
3 –
System status
4 –
0: Zone Normal
1: Alarm
2: Zone Bypassed
3: Zone Trouble
5 –
8: Disarmed
9: Armed
6 –
0: Normal
1: Panic/Duress
2: Fire Alarm
3: Medical Alar
7 –
0: AC Normal
1: AC Failure
8 –
0: System Normal
1: System Fault
