Bosch Split CS SM048 User Manual

SM Split CS Series Heat Pump
SM Split CS Series Heat Pump8733825873 (2020/05)
32 | Operating Temperatures and Pressures
Subject to change without prior notice
OPERATING TEMPERATURES AND PRESSURES
Table 17 SM024 Operating Temperatures and Pressures
Operating Temperatures and Pressures
Cooling Heating
Model
Entering
Water
Temp. F
Water
Flow
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp.
Rise °F
Air
Temp.
Drop °F
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp.
Drop
Air
Temp.
Rise °F
SM024
PART
LOAD
30°
4 71–91 264–322 5–6 15–17
8 79–96 270–331 3–4 16–18
40°
4 88–107 277–339 6–7 17–20
8 115–140 175–214 8–9 19–23 92–112 284–348 4–5 18–21
50°
4 129–157 218–267 14–17 18–20 98–122 291–356 7–8 20–23
8 124–151 204–250 8–9 19–22 110–130 298–364 5–6 21–24
60°
4 134–163 294–305 13–16 17–20 112–136 304–372 8–10 22–26
8 128–156 233–287 8–9 18–21 117–143 312–381 6–7 23–28
70°
4 138–168 281–341 13–16 17–19 124–152 318–389 9–11 24–29
8 133–161 263–323 7–9 18–21 131–159 325–398 6–8 26–31
80°
4 143–174 317–388 13–16 16–19 136–166 331–405 11–13 27–32
8 137–167 297–366 7–9 17–20 143–174 339–415 7–9 28–33
90°
4 147–179 357–437 13–16 16–18
8 141–172 335–411 7–9 17–20
100°
4 151–185 402–492 13–15 15–18
8 146–177 378–459 7–9 16–19
SM024
FULL
LOAD
30°
4 76–92 242–297 3–4 13–14
8 80–97 249–304 2–3 13–15
40°
4 125–151 180–221 14–18 19–22 89–108 255–312 4–5 15–17
8 120–146 169–207 8–10 20–23 93–113 261–320 3–3 16–18
50°
4 134–163 221–258 14–18 18–21 106–118 267–327 5–6 17–19
8 129–157 198–242 8–10 19–23 110–126 274–335 3–4 18–21
60°
4 139–169 241–295 14–17 18–21 113–138 280–342 6–7 19–22
8 134–163 227–278 8–10 19–22 119–145 287–351 4–5 20–23
70°
4 144–175 272–333 14–17 17–20 126–155 292–358 7–8 21–24
8 138–168 255–313 8–10 18–21 133–162 300–367 5–6 22–26
80°
4 148–181 307–375 14–17 17–19 138–168 305–373 8–9 23–27
8 143–174 288–353 8–10 18–21 145–177 312–382 5–6 24–29
90°
4 153–186 346–423 14–17 16–19
8 147–179 325–398 8–9 17–20
100°
4 158–191 389–477 13–16 16–18
8 152–185 366–448 8–9 17–20
This chart shows approximate temperatures and pressures for a unit in good repair. The values shown
are meant as a guide only and should not be used to estimate system charge. This chart assumes rated
airflow and 80º d.b./67º w.b. entering air temperature in cooling, 70º d.b. entering air temperature in
heating. Heating data at entering fluid temperatures below 50º assumes the use of antifreeze. As a result
of continuing research and development, specifications are subject to change without notice.
