Product information
19
Stora – 6721835329 (2023/06)
1000-litre cylinder
• Storage cylinder
• Floor insulation
•Casing lid
• Upper insulation
• Technical documents
• Fibre insulation with PVC outer layer
2.7 Product description
Table 18 Product description (
Fig. 1 - 3, page 33 - 34)
2.8 Type Plate
Table 19 Type Plate
Pos. Description
1 Heating water inlet
2 Heating water outlet
3 Rigid foam thermal insulation
4 Vent valve
5Foil jacket
6 Data plate
7 Heating water outlet
8 Heating water inlet
9 Installation options, electric heating
10 Installation options, electric heating
11 Installation options, electric heating
12 Installation options, electric heating
13 Installation options, electric heating
14 Installation options, electric heating
15 Sensor pocket at bottom (only with BP 1000 E)
16 Sensor pocket at centre (with BP 200 EK+BP 500 EP
accessory)
17 Sensor pocket at top (with BP 200 EK+BP 500 EP accessory)
18 Inspection aperture (only with BP 500 EP)
Pos. Description
1Type designation
2 Serial number
3 Nominal volume
4 Nominal volume of heat exchanger
5 Standby heat loss
6 Corrosion protection
7Year of manufacture
8 Maximum DHW temperature, cylinder
9 Maximum flow temperature, heat source
10 Maximum flow temperature, solar side
11 Heating water heat input
12 Volumetric flow rate of heating water for heating water input
power
13 Maximum operating pressure on the domestic water side
14 Highest design pressure
15 Maximum operating pressure, heat source side
16 Maximum operating pressure, solar side
17 Maximum operating pressure on the domestic water side CH
18 Maximum test pressure on the domestic water side CH
