Bosch SV030 User Manual

Constant Torque ECM Blower Motor | 29Revised 08/14
8 733 914 818 (2014/08)SV Heat Pump Series
CONSTANT TORQUE ECM BLOWER
MOTOR
Model
Voltage
Code
Rated Voltage
Voltage
Min/Max
Compressor Fan
Motor
FLA
Fan Motor
HP
Total Unit
FLA
Min
Circuit
Amps
Max
Fuse
QTY RLA LRA
SV015
1 208-230/60/1 197/253 1 5.6 29 2.8 0.33 8.4 9.8 15
2
265/60/1 240/292 1 4.6 20 2.6 0.33 7.2 8.4 15
SV018
1 208-230/60/1 197/253 1 6.5 43 2.8 0.33 9.3 10.9 15
2
265/60/1 240/292 1 5.8 46 2.6 0.33 8.4 9.9 15
SV024
1 208-230/60/1 197/253 1 7.4 43 2.8 0.33 10.2 12.1 15
2
265/60/1 240/292 1 6.7 46 2.6 0.33 9.3 11.0 15
3
208-230/60/3 197/253 1 5.9 63 2.8 0.33 8.7 10.2 15
4
460/60/3 414/506 1 2.9 30 2.1 0.5 5 5.7 15
SV030
1 208-230/60/1 197/253 1 9.9 54 2.8 0.33 12.7 15.2 25
2
265/60/1 240/292 1 8.5 46 2.6 0.33 11.1 13.2 20
3
208-230/60/3 197/253 1 6.9 63 2.8 0.33 9.7 11.4 15
4
460/60/3 414/506 1 5.4 30 2.1 0.5 7.5 8.9 15
SV036
1 208-230/60/1 197/253 11374 4.1 0.5 17.1 20.4 30
2
265/60/1 240/292 1 11.3 67 3.9 0.5 15.2 18.0 25
3
208-230/60/3 197/253 1 7.8 68 4.1 0.5 11.9 13.9 20
4
460/60/3 414/506 1 3.9 34 2.1 0.5 6 7.0 15
SV041
1 208-230/60/1 197/253 1 13.6 88 6 0.75 19.6 23.0 35
3
208-230/60/3 197/253 1 8.8 68 6 0.75 14.8 17.0 25
4
460/60/3 414/506 1 4.4 34 4.6 0.75 9 10.1 15
SV042
1 208-230/60/1 197/253 1 13.6 88 6 0.75 19.6 23.0 35
3
208-230/60/3 197/253 1 8.8 68 6 0.75 14.8 17.0 25
4
460/60/3 414/506 1 4.4 34 4.6 0.75 9 10.1 15
SV048
1 208-230/60/1 197/253 1 15.7 84 6 0.75 21.7 25.6 40
3
208-230/60/3 197/253 11188 6 0.75 17 19.8 30
4
460/60/3 414/506 1 5.4 44 4.6 0.75 10 11.4 15
SV060
1 208-230/60/1 197/253 1 26.3 145 7.6 1 33.9 40.5 60
3
208-230/60/3 197/253 1 15.6 123 7.6 1 23.2 27.1 40
4
460/60/3 414/506 1 7.8 70 4 1 11.8 13.8 20
SV070
1 208-230/60/1 197/253 1 28.3 158 7.6 1 35.9 43.0 70
3
208-230/60/3 197/253 1 19.2 155 7.6 1 26.8 31.6 50
4
460/60/3 414/506 1 8.7 75 4 1 12.7 14.9 20
