18 | WBE 4100 | Symbols useden
Contents 1. Symbols used
1.1 Documentation
Pictograms linked with the key words Danger, Warning
and Caution are warnings and always indicate an imme-
diate or potential hazard to the user.
Danger!
Immediate danger that could cause serious
personal injury or death.
Warning!
Potentially dangerous situation that could
cause serious personal injury or death.
Caution!
Potentially dangerous situation that could
cause personal injury or damage to property.
! Important – warns of a potentially hazardous situa-
tion in which the WBE 4100, the test sample or other
object in the vicinity could be damaged.
In addition to these warnings, the following symbols are
also used:
i Info – In addition to these warnings, the following
symbols are also used.
¶ Single-step procedure – instructions for a procedure
that can be completed in just one step.
? Intermediate result – an intermediate result is dis-
played during a procedure.
"Final result – the final result is displayed at the end
of the procedure.
1.2 WBE 4100
Disposal
Old electrical and electronic devices, including
cables and accessories or batteries must be
disposed of separate to household waste.
1. Symbols used 18
1.1 Documentation 18
1.2 WBE 4100 18
2. Introduction 19
2.1 Digital balancing machine WBE 4100 19
3. How to use the machine and surfing menu 19
3.1 Configuration of the use 19
3.2 Configuration of the board 20
3.3 Self-calibration 20
3.4 Auto-diagnosis 20
4. Problems and error codes 21
5. Use configuration 23
6. Configuration of the board 23
7. Calibration menu 23
8. Auto-diagnosis menu 24
8.1 Msr 24
8.2 Enc 25
8.3 Sp 25
8.4 A 26
8.4.1 A0 26
8.4.2 A1 26
8.4.3 A2 e A3 27
8.4.4 A5 27
8.4.5 A7 27
8.5 INP 28
8.6 CNT 28
8.7 LED 28
8.8 TAR 28
8.9 REL 28
9. Substitution of the board 29
10. Suggested spare parts 29
11. Electrical system 30
