Bose 1800-V User Manual

50
Reference
Designator
Description Part Number Reference
C1 .1UF,250VAC,
MTPOLY,UL/CSA
182846
C2 330µF,20%,25V,
LYTIC,RAD
182946
C3,8 47µF,20%,25V,LYTI
C RAD .2
182896
C4,5 150 pF,10%,1000V,
Cer. Disc
182944
C6 .1µF,5%,100V,
PLYFLM,RAD
182945
C7 10µF,20%,50V,
LYTIC,RAD
182895
C9,10 .01µF,100V,Cer.
MULTILYR,RD
182780
Reference
Designator
Description Part Number Reference
D2,3 Zener,1N4736A,
6.8V
182961
D4,5,7-9 1N4148,75V 182868
D6 Zener,1N4735A
6.2V
182962
Reference
Designator
Description Part Number Reference
Q1 TO92,NPN,SM SG,
2N4123
182913
Capacitors
Diodes
Transistors
