Bose 1800-V User Manual

55
Resistors
Reference
Designator
Description Part Number Reference
R1 MO FP 5% 130 3W
.9 AX SM
182932
R2 910Ω,5%,1/4W,
FLMPRF
182810
R3 27KΩ,5%,1/4W,CF 182903
R4 20KΩ,5%,1/4W,CF 183021
R5 10KΩ,5%,1/4W,CF 182789
R6 6.2KΩ,5%,1/4W,CF 182930
R7 47KΩ,5%,1/4W,CF 182928
R8 WW 5% 91 7W 1.3
AX
182936
R11 56KΩ,5%,1/4W,CF 182929
R100,200 6.8Ω,5%,5W,MO
1.2 AX SM
182934
R102,202 MO FP 5% 470 2W
1.0 AX LG
182933
R103,203 WW LRES 5% .02
5W 1.2 AX
182935
R110,210 1Ω,5%,5W,1.2,MO,
AX SM
182931
R111,211 1Ω,5%,1/4W,
FLMPRF
182861
R112,113,212,213 10Ω,5%,1/4W,
FLMPRF
182937
R114,214 1.1KΩ,5%,1/4W,CF 182926
Reference
Designator
Description Part Number Reference
C1,2,101,201 .01µF,20%,500V,
Cer. Disc
182836
C3 4.7µF LYTIC,20%,
35V,LL RD
182925
C4 4.7µF, LYTIC 63V
20% RAD .2
182924
C100,200 .33µF,10%,400V,
METPOLY RD
182923
Reference
Designator
Description Part Number Reference
D100,101,200,201 1N4004 400V PREP 182811
Output PCB Electrical Part List
Capacitors
Diodes
