9
Setting Up
1. Connect the wire pair marked
CENTER
to the center cube speaker (Figure 5). Press the termi-
nal tab on the back of the cube speaker. Insert the marked (+) wire into the red terminal and
the plain (–) wire into the black terminal. Release the tab to secure the wires.
2. Connect the wire pair marked RIGHT to the right front cube speaker (to the right of the
TV as you face it).
3. Connect the wire pair marked LEFT to the left front cube speaker.
4. Plug the other end of each cable into the
Center Front
,
Right Front
, and
Left Front
blue RCA
jacks, respectively, on the Acoustimass
®
module.
Connecting rear cube speakers to the Acoustimass module
Each rear cube speaker is connected to the Acoustimass module with a 50-foot (15 m)
speaker cable (
Figure 5). Be sure to match the correct cable with the corresponding speaker
location. Rear speaker cables have orange RCA connectors at one end with LR (left rear) and
RR (right rear) molded into the connectors. The other ends of the cables have two wires. The
red collars on the + wires are labeled LEFT REAR and RIGHT REAR.
1. Connect the wire pair marked RIGHT REAR to the right rear cube speaker (on your right
as you face the TV). See
Figure 5. Press the terminal tab on the back of the cube speaker.
Insert the marked (+) wire into the red terminal and the plain (–) wire into the black termi-
nal. Release the tab to secure the wires.
2. Connect the wire pair marked LEFT REAR to the left rear cube speaker.
3. Plug the other end of each cable into the Right Rear and Left Rear orange RCA jacks,
respectively, on the Acoustimass module.
