12
Setting Up
Checking the connections
Check all connections from the receiver to the Acoustimass
®
module and from the module to
the cube speaker arrays (Figure 5 and Figure 6). Make sure all cube speaker arrays are con-
nected to the proper terminals according to their position in your room. Check that all wires
are connected to your surround receiver in phase (+ to + and – to –). Incorrect wiring can
result in a total loss of module output. Correct wiring problems before you plug your receiver
in and turn it on.
Connecting the Acoustimass module to power
Note: Bose
®
recommends using a quality surge suppressor on all electronics equipment.
Voltage variations and spikes can damage electronic components in any system. A quality
suppressor can eliminate the vast majority of failures attributed to surges and may be pur-
chased at an electronics store.
After you have checked all system connections, plug the power cord of the powered Acousti-
mass module into an AC (mains) receptacle. Your Acoustimass speaker system will turn on
and off automatically as it receives a signal from your surround receiver.
Upgrading your Acoustimass 15 Series II speaker system
Your Acoustimass 15 Series II speaker system can be upgraded to provide you with 6.1 or
6 channel surround sound.
The 6.1 upgrade kit contains one black (PC 029661) or white (PC 029662) cube speaker array,
a 50-foot connecting cable, and complete connection instructions.
To purchase the 6.1 upgrade kit, contact your local authorized Bose retailer or call Bose
directly. See the list of Bose offices and phone numbers enclosed with your system. When
ordering, you will need to know the serial number of your Acoustimass module.
AM264924_00 _V.pdf • August 13, 2002
